Wall Mounted Electric Boiler Product Parameters:
NO. | Product model | Unit | LC-B-6kw | LC-B-8kw | LC-B-10kw | LC-B-12kw | LC-B-15kw |
1 | Rated power | KW | 6 | 8 | 10 | 12 | 15 |
2 | Rated current | A | 27.3 | 36.4 | 45.5 | 48.2 | 52.8 |
3 | Heating area | ㎡ | 60-80 | 80-100 | 100-120 | 120-140 | 150-180 |
4 | input voltage | 50HZ | 220V | 220V | 220V | 220V/380V | 220V/380V |
5 | Minimum flow of water pump configuration | L/min | 15 | 15 | 20 | 20 | 25 |
6 | Hot water yield 50 ℃ | L/min | 5.62 | 3.75 | 4.69 | 5.62 | 6.9 |
7 | Design thermal efficiency | ℃ | 98% | 98% | 98% | 98% | 98% |
8 | Maximum water temperature | ℃ | 85 | 85 | 85 | 85 | 85 |
9 | Low temperature protection temperature | ℃ | 5 | 5 | 5 | 5 | 5 |
10 | Size (length * width * height) | mm | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 |
11 | Water inlet and outlet interface | DN | 32 | 32 | 32 | 32 | 32 |
Product Details:
Why choose us ?
Main uses of wall mounted electric boiler:
The main uses are not only for heating, such as hot water for hotels, bathing water for coal miners, drinking water for schools, industrial production water, or other liquid heating. Electromagnetic heating can be used.
Wall Mounted Electric Boiler Long Service Life And Low Power Consumption
Working Principle Of Wall Mounted Electric Boiler:
The operating principle of the wall mounted electric boiler is that the electromagnetic induction magnetic field directly causes the metal pipe to heat itself. Water or some other liquids are circulated to the metal pipe, and are heated during the circulation. When they come out, they are hot water or hot liquids.
What are the advantages of wall mounted electric boilers:
1. The higher the outlet water temperature of the wall mounted electric boiler, the more heat will be released for the heating space, and the better the heating effect will be.
2. The electric heating furnace is made of high-quality materials, advanced design technology, excellent workmanship, small volume, light weight and convenient installation; Voltage pre control, heating and preheating, and calculation control are all perfectly designed to reduce the consumption of equipment in the process of use.
3. Household ordinary voltage heating, no harmful gas and residue emission, clean and sanitary. Constant temperature control, regular on and off, and reasonable utilization of electric energy. The electric heating furnace has no motor noise and air pollution. There is no sense of blowing and erosion to people when the wind circulates, and no parasitism of pathogenic microorganisms.
4. It is mainly equipped with double leakage protection, anti dry burning protection, mute system to reduce noise pollution, remote control indoor, over temperature alarm and safety.
