Electric Heating Furnace Industrial Commercial Heating Hot Water Boiler
Overview of electric heating furnace:
Electric heating furnace is also known as electric heating boiler and electric heating boiler. As its name implies, it takes electric power as energy and converts it into heat energy. It is a boiler equipment of high temperature water or organic heat carrier. The body of electric heating furnace is mainly composed of steel shell of electric boiler, computer control system, low voltage electrical system, electric heating pipe, inlet and outlet water pipes and detection instruments.
Product technical parameters:
Serial number | Product model | Company | LC-B-6kw | LC-B-8kw | LC-B-10kw | LC-B-12kw | LC-B-15kw |
1 | Rated power | KW | 6 | 8 | 10 | 12 | 15 |
2 | Rated current | A | 27.3 | 36.4 | 45.5 | 18.2 | 22.8 |
3 | Heating area | ㎡ | 60-80 | 100-120 | 100-120 | 120-140 | 150-180 |
4 | input voltage | 50HZ | 220V | 220V | 220V | 220V/380V | 220V/380V |
5 | Minimum flow of water pump configuration | L/min | 15 | 15 | 20 | 20 | 25 |
6 | Hot water yield 50 ℃ | L/min | 5.62 | 3.75 | 4.69 | 5.62 | 6.9 |
7 | Design thermal efficiency | ℃ | 98% | 98% | 98% | 98% | 98% |
8 | Maximum water temperature | ℃ | 85 | 85 | 85 | 85 | 85 |
9 | Low temperature protection temperature | ℃ | 5 | 5 | 5 | 5 | 5 |
10 | Overall dimension (length * width * height) | mm | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 | 360*170*630 |
11 | Water inlet and outlet interface | DN | 32 | 32 | 32 | 32 | 32 |
Advantages of semiconductor electric boiler:
1. Modular structure, the scheme is more flexible, which can be used for household heating and central heating.
2. No scaling, no wearing and consumable parts, long-term energy saving.
3. Separation of water and electricity: the complete separation of water and electricity fully avoids the potential leakage hazards of electrical equipment, so that users have better security.
4. Intelligent control; The temperature control can switch between manual and automatic freely, and can display four modules: temperature, time, heating and alarm.
5. Moderate cost
6. The insulator is ceramic sheet, and the initial thermal conversion rate is 98%, but the half-life cycle of ceramic sheet is short, and the annual thermal conversion rate decreases by about 7%. About 6-10 years.
Application fields:
Electric heating, hot water and industrial steam are used in factory workshops, office buildings, schools, hotels, hospitals, greenhouses, administrative units, offices, villas, residential quarters, bathing centers, swimming pools, etc.
